Your present position：Home > Smart home > Electric curtain controller
|
Intelligent control |
Power-off |
|
Mobile phone APP precision control , gesture control , remote wipe control |
Can be like ordingary curtains in power-off state , use hand gently pull the curtains to complete the opening or closing |
| In case of resistance | Central control interface weakness conttol function |
| Pull the curtains the process of opening or closing , when the curtains encounter resistance will automatically stop running | The head of the motor can be through the dry contact interface , RS232 , RS485 and other means compatible with intelligent system |
| Touch to start | Wiresless remote control |
|
Use hand to pull the curtains , in a certain direction , the curtains automatically run untill they are completely open or fully closed and automatically stoped |
can penetrate pbstacles or walls , any direciton sensitive to receive |
| Slent design | Strke memory |
|
wotj stepless variable speed mute , industry- leading clutch technology , runing noise less than 35 dB |
memry limit function , without manually setting the travel limit , geatly reducing the installation and commissioning time . when the user use in long time , electronic memory limit function can automatically eliminate the daily stroke cumulative error , so that its stroke positioning can keep accuracy in long-term |
|
The main function parameters of electric curtain motor |
|
| Product name ： Electric curtain motor | Dimensions ： 66mm*50*233mm |
| Podict weight ： 1.1KG | Guide ： can be customized according to user needs right-angle , U-shaped , curved guide |
| Rated voltage ： 220V |
Open the closing speed ： 20cm/sec |
| Contact working hours ： 4min | product type ： KT320E-45/20 |
|
Track length ： <12 m |
Rated current ： 0.23A |
| Product Type ： KT320E-45/20 | Safe load ： 50KG |
| Maximum power ： 45W | Guide ： can be customized according to user needs right - angle , U-shaped , curved guide |
